NEW CARGO SPACE AND REAR EXTENSION

The new cargo space is a type of manual VLS available for 26.5 axles and fixed grate or hydraulic horizontal movement grate. The loading surface measures 4.1 - 4.4 m2 and the width of the machine is 2,820 - 3,040 mm.

The new 600mm rear extension is ideal for 2 x 3m stacks. New bed positions for 2 x 2.5m stacks will also be introduced. The rear extension is available for 26.5 axles with a loading area of ​​4.0 m2 and the option of a longer rear frame of 5200 mm.

LONG BOGIE

Now with a 390mm wheel increase between the front and rear axles. Retains the drive train and turning spokes of the standard HD bogie-equipped portal machine. This machine is ideal for felling on soft ground since the front and rear chassis exert low pressure on the ground.

ROTATING AND LEVELABLE CAB

John Deere designs a comfortable and ergonomic work environment for the forestry operator. The comfort of the cabin influences productivity, for this reason the rotating and leveling cabin helps the operator to avoid overloading the back and shoulders. The cab swivels in all directions giving the forestry operator a position facing the work area. In addition, the vibration absorption system optimizes working conditions.

EXACT LOCATION OF EACH LOG

John Deere TimberMatic Maps allows the forestry operator to get a real-time production view of the logging area. The data collected by the harvester's sensors and the exact GPS-based location of the felled timber is automatically transmitted from the harvester to the TimberMatic app for use by the forwarder operator. In TimberMatic Maps you can highlight different selections with different colors by marking them as favorites. In addition, the operator through the classifiers can speed up the loading and unloading of the wood.
